5V DC min blower 3pin 5000RPM FG blower fan 50*50*10mm
Bearing Type-------------Axially-grooved Bearing
Frame and Impeller--------L.C.P.(UL94V-0),IP57
Voltage-----------------DC 3.3V 5.0V
Temperature range-------- -10℃ to +60℃
Expected Life------------ 25000 hours
Insulation Resistance------10MEGA.Ω Min. at 500VDC(between frame and (+) terminal)
Dielectric Strength--------5mA Max. at 500VAC,60Hz,One Minute(between frame and (+) terminal)
<iframe width="600" height="460" src="https://www.youtube.com/embed/QMl5rwqtRHo" frameborder="0" allow="accelerometer; autoplay; encrypted-media; gyroscope; picture-in-picture" allowfullscreen></iframe>
Specifiction
| (Item) | (Specification/Condition) |
| (Mode1 No.) | MX5010GBH5 |
| (Outline. Dimension) | 50*50*11mm |
| (Operating Voltage) | DC 4.5V-5.5V |
| (Rated .voltage) | DC 5V |
| Starting Voltage | DC ≤3.0V on/off |
| (Rated current) | 0.20A±10% | a. (Rated .voltage) b.25℃ 65% RH c.After testing for 5 minutes |
| (Power consumption) | 1.0W±10% |
| (Speed) | 5000±10%RPM |
| (Max Airflow) | 3.61CFM | a. (Rated .voltage) b. AMCAStandard C. (Rated current) |
| (Max Air .Static Pressure) | 7.93mmH2O |
| (Max Noise Level) | ≤30.12dB | a. (Rated Voltage) b. (Non-Echo Chamber) c. (Standard):CNS 8753 / ISO 3744 d. Test Condition :ISO 7779 e. (Distance): 1.0 M |
| Life expectancy | 50000Hrs 25℃ | MTTF (Mean Time To Failure) Conf. Level 90%) |
| (No.of.Blade) | propeller blade |
| (No.of.Pole) | 4 pole |
| (Rotating Direction) | clockwise |
| Lock Protection | YES |
| Polarity Protection | YES |
| (Overvoltage protection) | NO |
| (Overcurrent protection) | NO |
| FG | NO |
| PWM function | YES |
Manufacture Process
More fans
Manufature accroding to your demend, Size from 15mm to 1000mm, With FG RD PWM IP58 IP68 waterproof and dustproof function
Extensive application
Our sevice
Packing:
Carton box or according to customers demand
Shipment:
1. FOB Shenzhen or HongKong (mass production)
2. DHL,UPS,FEDEX,TNT or any other international express (sample or small quantity)
Delivery Time:
Generally, 500~1000pics 10 days after confirming the PI
Payment:
T/T and paybal
1. The payment for the high value sample will be charged.
2. The payment for the low value sample is free, but the freight should be paid by you.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for but not free
Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
Product Tags:
|
|
5V DC Min Blower 3 Pin Fan 4000RPM PWM Lightweight With 50mm X 50mm X 10mm Images
|
